Alternating Autonomous Vehicle

Introducing a new anti-collision safety system for vehicles

“To make a safety system for cars which are travelling on high speeds(e.g. on highway) and they face a halted obstacle which they cannot bypass(e.g. animal, accident, foggy weather)”

Objective

Team

M. Abdullah Umair

Project Manager

The undeniable initiater. Contributed and invested the most time in project.

M. Musab Khan

Project & Website Maker

The inevitable project maker. Helped with everything and designed the website.

M. Yousuf Jamil

App Developer & Website

The unique Android App developer. Also initiated the layout of website.

M. Musab bin Moin

Display Manager

Assisted in making the car's base and for chart display.

M. Anas Quzafi

Assistant

Helped in making the car's base and providing some materials.

Features

1

Driving

Using wired joystick, the car demonstrates and acts as if a person in controlling and driving it.

2

Auto-turning & Auto-Drifting

In emergency situation, the car uses a sonar system to detect whether there is any obstacle present on its right or left, and turns if nothing is detected. If left and right are occupied and nothing behind, the car drifts to avoid explosion.

3

Auto-braking with ABS

If the car is occupied by right, left and back side, the car simply starts auto-braking with help of ABS to limit the damage of collision.

Results

Right Turning

# Obstacles E.R. Results Collision Success Times
1 front, left(long) turns right turns right FALSE 100% 5
2 front(long), left turns right turns right FALSE 100% 5
3 front turns right turns right FALSE 100% 5
Success Rate: 100%


Left Turning

# Obstacles E.R. Results Collision Success Times
1 front, right(long) turns left turns left FALSE 100% 5
2 front(long), right turns left turns left, 80% 20% 70% 5
3 front turns right* turns right FALSE 100% 5
Success Rate: 90%


Drifting

# Obstacles E.R. Results Collision Success Times
1 front, sides(near & long) drifts drifts FALSE 100% 2
2 front, sides(far) turns right* turns right FALSE 100% 2
3 front(long), sides(near & long) drifts drifts FALSE 100% 2
Success Rate: 100%

Overall success rate: 97%

E.R. is Expected Results

* is preferential right turning(KSA compliant)
